Air2 User Manual

Thank you for choosing this product. Please read the user instruction carefully before use.

Not a medical device and not intended to provide medical or scientific data



Attach and remove a band

1) Insert the needle of watch band to the hold

2) Toggle the lifting lever of the watch band and push it into the slot for fixing

3) Pull the watch band gently after finishing assembly to ensure it will not drop

Toggle the lifting lever of watch band to take down the watch band





About the watch

Power Button

Power on
Long press the power button for a few seconds to turn on the watch
Power off
Long press the power button for a few seconds to select close, restart, or cancel

Press the power button to switch the display interface from any other page to watch face.

When the display interface is watch face, press this button to open the watch’s app menu.

When the display interface is the watch’s menu, double-click this button to change the menu style.

Sports Button

Press the sports key to immediately enter the exercise list interface



UI touch

Slide left or right the interface to view the shortcut card or sidebar.

When the display interface is watch face, slide it up to view the notification panel;

Slide it down to open the control center.



Notes:

1) For first use, please charge up the watch to activate it.

2) If the watch cannot be powered on, please fully charge it up, and then have another try.



How to Pair the watch?



To ensure a smooth connection between your watch and smartphone, please follow these steps:

1.Charge Your Watch: When using the watch for the first time, it's essential to charge it for a minimum of 2 hours to ensure a full charge.

2.Enable Bluetooth: Keep the smartphone Bluetooth turning on.

3.Check Smartphone Compatibility: Ensure your smartphone meets the following requirements:

Android 6.0 & iOS 10.0 and above. The smartphone is connected to cellular data or WLAN.

4.Download the FitCloudPro app: Search for "FitCloudPro" on “App Store” or "Google Play Store”.

(Attention: It’s totally free to download and use the app. Please do not click on any other advertising apps or links!).



5. Create your APP account: After installing the FitCloudPro app, tap “Join Us” to create a new account (or Use Without Account/visitor mode)

Note: To calculate your steps, walking and calorie burning, please fill in your primary body information correctly.

6.Connect your watch: When account creation is complete, go to the "Device” page and click "+Add Peripheral Now" or "+Bind Device" to the device search page.

Click the watch's Bluetooth name to make pairing. Tick "Agree" binding request on the watch to confirm pairing. Once pairing succeeds, the watch will turn to watch face automatically.

7.Allow notifications: After connection, the App will pop up "Allow watch to receive notifications from your phone", please click " Allow". If not, the watch will not receive message notifications.

Notes:

1) During pairing, please confirm your phone’s Bluetooth is on, the watch is not on Power saving mode or low battery, and ensure the watch is connected to your phone.

2) If the watch cannot be searched during device adding, or if the watch cannot be connected at use, please reset/reboot it, and then have another try

3) Once pairing successfully, please follow the app guidelines to protect backstage from being closed by the phone system. Otherwise, the watch may be disconnected from your phone, affecting the normal operation of the watch.

4) For a better user experience, please use the latest version of the app. The required operating system should be above Android 6.0 or iOS 10.0.



How to disconnect the Bluetooth?

You can open your phone's Bluetooth settings, select your watch's Bluetooth name, and click "Ignore this device".



1. Open the FitCloudPro app, click on “Device”, and then “Unbind”

2. After unbinding, the app will pop up a Bluetooth ignore window. Click to go to Bluetooth settings and ignore the device name of the watch in the Bluetooth list.

Attention: if you didn’t enter the Bluetooth settings in the pop-up window, please open your phone’s Bluetooth settings and ignore the device.

How to wear the Watch

1. wear the watch properly, not too tight or too loose to allow your skin to breathe. Wear it in comfort, and the sensor could operate normally.

2. For accurate measurement, please keep your arm level and still, and keep your skin comfortable, leaving a finger space between watch and skin.

3. You could tighten the watch band during exercise and loosen it after exercise.

4. The tattoo, mark and hair on your wrist where the watch is worn may affect the heart rate sensor. For this reason, please wear the watch on a wrist that will not disturb its function.



Note:

1) Once the watch band is well fit, you can pull it to check whether it’s secure or not.

2) If the watch band breaks, please contact the manufacturer for renewal.



Main functions

Swipe the screen right to enter the main functions list interface.

 Heart rate

1. Click “Heart rate” on the watch’s menu.

2. The watch will begin to measure your heart rate.

3. Wait for about 10 seconds, and then you could view the measured heart rate.

4. Slide the interface up or down to view other information about heart rate. You could turn on Bluetooth, synchronize the information on heart rate with the app, and view further heart rate data.



SpO2

1. Click “Blood oxygen” on the watch’s menu.

2. The watch will begin to measure your SpO2.

3. Wait for about 10 seconds, and then you could view the measured SpO2.

4. Slide the interface up or down to view other information about SpO2. You could turn on Bluetooth, synchronize the information on SpO2 with the app, and view further data of SpO2.

Blood Pressure monitor
Supports 24/7 Blood Pressure tracking. To turn on 24/7 Blood Pressure monitor feature: Go to FitCloudPro APP -- Device--Automatic Health Monitoring--Switch on

Sleep

1. Sleep with the watch, and it will track your sleep automatically.

2. When you wake up, click “Sleep” on the watch’s menu, and then you can view the information on sleep for the previous night.

3. You could turn on Bluetooth, synchronize the information on sleep with the app, and view further data of sleep.



Exercise

Swipe right on the screen to enter the main functions list interface and find “Workout”. Select the desired sport mode to start recording your workout.

 The watch will begin to record your exercise data automatically in 3 seconds. Slide up or down the interface to view heart rate, distance, sports time, etc. Slide right the interface to go back to finish exercise.

You can turn on Bluetooth, synchronize the information on exercise with the app, and view further data of exercise from the plate Sports Record on Homepage.

Add more sport mode from FitCloudPro to the watch: Go to the app=>Devcie=>Sports Push=>select the sports you want.



Daily exercise data

Click “Data” on the watch’s menu, and you could view information on your current steps.

1) Steps: View your steps for the day. The closer the number of the steps is to the goal, the larger the graphical progress.

2) Calories: View your calories consumed for the day. The closer the number of the calories is to the goal, the larger the graphical progress.

3) Distance: View your walking distance for the day. The closer the exercise distance is to the goal, the larger the graphical progress.



How to set a goal

1. Turn on Bluetooth. Ensure the watch is connected to your phone.

2. Open the FitCloudPro,find the plate “Exercise Goal/Target” on “Me” page.

3. Click the desired data type, and set your goal.



Message Notification

1. When the watch is connected to your phone via Bluetooth, the watch could read messages from your phone’s notification center.

2. When the display interface is watch face, slide it up to open the notification panel, and then the message notifications could be viewed.



Weather

1. Turn on Bluetooth. Ensure the watch is connected to the app.

2. Open the FitCloudPro

3. Click “Device” page

4. Turn on “Weather report” option and allow the prompt for Location permission.

5. Open the watch’s menu, click “Weather” to view local weather information.



Notes:

Conditions for the weather to update weather data.

1) The app has been granted location permission.

2) Your phone is in the normal state of network connection;

3) The watch Bluetooth connection is normal.

4) In all the above conditions, the watch will update temperature every two hours. If air temperature remains unchanged, please close the app backstage and re-open it.



Watch face

1. Long-press and hold watch face to enter “Edit” interface. Slide the interface left or right, and then select the desired watch face.

2. Turn on Bluetooth, ensure the watch is connected to your phone. You could open the FitCloudPro and select more watch faces from Dial library.

3. Alternatively, you could upload a picture to generate a user-defined watch face.

How to charge up the watch

1. Wire the charging cable to the power adapter or USB port on your computer.

2. Align the charging port tightly with the charging contacts on the watch’s back.

3. When charging, you can view the charging status on the screen.

4. When the watch is fully charged, please remove it from the wireless charger.



Notes:

1) Please use the charging cable in the package.

2) Before charging, please ensure the charging port is dry, clean, free of sweat, liquid, dust, and so on.

3) If the watch is in standby state for a long time, it is recommended to power off the watch before putting it on hold. The watch should be fully charging every 1-2 months and checked when turned on to avoid excessive battery discharge resulting in it cannot be powered on.



Attention

1. This product, not a medical apparatus, shall not substitute for professional medical diagnosis. Its design or intention is not to diagnose diseases and other symptoms nor is it intended to cure, relieve, treat or prevent any symptom or disease. Before making any decision on your health, please seek advice from your healthcare service provider.

2. Do not allow children and pets to bite or swallow this products or its accessories. Otherwise, they probably get hurt.

3. Keep this product away from over-temperature and under-temperature conditions. Otherwise, a fire or explosion may occur.

4. The Company has internal and external certification agencies to do harmful material testing for the watch, covering all materials worn in direct contact with the skin. Some people may show skin allergies to vinyl leather, fiber, etc., and symptoms such as erythema and inflammation will occur after long contact with this product. If you have such symptoms, please stop using the product right away, and seek advice from your doctor.



5. Please don't use an unauthorized/incompatible power charger or data cable. Otherwise, the watch may be damaged, catches fire, explodes, or leads to other dangers.

6. Radio waves from this product probably affect availability of implantable/personal medical apparatuses such as cardiac pacemaker and hearing aid.

7. Please don't dispose of this product and its accessories as general household garbage. Please ensure you dispose of or recycle this product and its accessories in accordance with local laws and regulations.

8. Do not replace battery with an incorrect type.

9. Do not put the battery in the fire or a hot oven, or mechanically crush or cut a battery, so as not to cause explosion.

10. Do not place battery in an extremely high temperature surrounding environment so as not to cause explosion or the leakage of flammable liquid or gas.

11. Do not place the battery in an environment with extremely low air pressure, which may lead to explosion or flammable liquid or gas leakage.

12. Do not use in low air pressure at high altitude condition.

13. Do not use at high or low extreme temperatures.
